Manley 594100C-8 4.6L / 5.4L Platinum Series -11cc Dish Pistons 3.552" Bore
MAN-594100C-8
Was:
$829.99
Sale:
$788.49
Save:
5%
Save:
$41.50
Description
.
- 2618 High Strength Material, Lightweight Design
- 1.2mm Offset Wrist Pin Location for Quiet Startups - Mimics OEM Design
- Perfect Ring Groove to Skirt Squareness
- Pressure Balance Groove
- 2.500" Premium 4130 Chrome Moly Wrist Pins included with Round Wire Locks
- Fully Banded Skirt Design for Increased Skirt Stability
- 1.5mm x 1.5mm x 3mm Ring Stack
- 9310 Alloy Wrist Pin upgrade available - Recommended for 800+ HP
Specifications
| Part Number | 594100C-8 |
| Bore | 3.552" |
| Dish Volume | -11cc Dish |
| Compression Height | 1.220" |
| Stroke | 3.543" / 4.165" |
| Rod Length | 5.933" / 6.657" |
| Wrist Pin | .866" x 2.500" |
| Wrist Pin Material | 4130 Chrome Moly / 9310 Tool Steel Available |
| Ring Stack | 1.5mm x 1.5mm x 3mm |
| Piston Weight | 350 grams |
Compression Ratios
| 2V PI 42cc | 2V NPI 51cc | 4V 52cc | |
| 4.6L | 10.53:1 | 9.29:1 | 9.18.1 |
| 5.4L | 9.61:1 | 8.72:1 | 8.64:1 |
Details
- MAN-594100C-8
- MAN-594100C-8
- Manley
- New
Shipping Information
- Item Requires Shipping
- 15.0 lbs.
- W12.0000” x H6.0000” x L18.0000”
- Free Shipping!
