Manley 595030C-8 4.6L Stroker Platinum Series Flat Top Pistons 3.582" Bore
MAN-595030C-8
Was:
$829.99
Sale:
$788.49
Save:
5%
Save:
$41.50
Description
- 2618 High Strength Material, Lightweight Design
- 1.2mm Offset Wrist Pin Location for Quiet Startups - Mimics OEM Design
- Perfect Ring Groove to Skirt Squareness
- Pressure Balance Groove
- 2.500" Premium 4130 Chrome Moly Wrist Pins included with Round Wire Locks
- Fully Banded Skirt Design for Increased Skirt Stability
- 1.5mm x 1.5mm x 3mm Ring Stack
- 9310 Alloy Wrist Pin upgrade available - Recommended for 800+ HP
Specifications
| Part Number | 595030C-8 |
| Bore | 3.582" |
| Dish / Dome Volume | Flat Top |
| Compression Height | 1.200" |
| Stroke | 3.750" |
| Rod Length | 5.850" |
| Wrist Pin | .866" x 2.500" |
| Wrist Pin Material | 4130 Chrome Moly / 9310 Tool Steel Available |
| Ring Stack | 1.5mm x 1.5mm x 3mm |
| Piston Weight | 360 grams |
Compression Ratios
| 2V PI 42cc | 2V NPI 51cc | 4V 52cc | |
| 4.6L 3.750" Stroke | 13.54:1 | 11.61:1 | 11.43:1 |
