Manley 598405C-8 5.0L Coyote Platinum Series Pistons -2.5cc Flat Top - 3.635" Bore
MAN-598405C-8
10:1 Compression Ratio
Was:
$849.99
Sale:
$807.49
Save:
5%
Save:
$42.50
Description
Compression Ratio: 10.0:1
- 2618 High Strength Material, Lightweight Design
- 1.2mm Offset Wrist Pin Location for Quiet Startups - Mimics OEM Design
- Perfect Ring Groove to Skirt Squareness
- Pressure Balance Groove
- 2.500" Premium 4130 Chrome Moly Wrist Pins included with Round Wire Locks
- Fully Banded Skirt Design for Increased Skirt Stability
- 1.2mm x 1.2mm x 3mm Ring Stack
- 9310 Alloy Wrist Pin upgrade available - Recommended for 800+ HP
Specifications
| Part Number | 598405C-8 |
| Bore | 3.635" |
| Dish / Dome Volume | -2.5cc Flat Top |
| Compression Height | 1.165" |
| Stroke | 3.650" |
| Rod Length | 5.933" |
| Valve Reliefs | 4V - Coyote Specific - will fit +1mm Valves |
| Wrist Pin | .866" x 2.500" |
| Wrist Pin Material | 4130 Chrome Moly / 9310 Tool Steel Available |
| Ring Stack | 1.2mm x 1.2mm x 3mm |
| Piston Weight | 368 grams |
Details
- MAN-598405C-8
- MAN-598405C-8
- Manley
- New
Categories
Shipping Information
- Item Requires Shipping
- 15.0 lbs.
- W12.0000” x H6.0000” x L18.0000”
- Free Shipping!
