Modular Head Shop 1200+ HP 5.0L Coyote Rotating Assembly - FRPP Boss 302 Crankshaft, Molnar PWR ADR H-Beam Rods and JE Ultra Pistons
MHS-500017C
Available in 10.0:1 and 11.0:1 Compression.
Pricing:
$3,419.00
Description
- FRPP Boss 302 Forged Crankshaft
-
Molnar PWR ADR H-Beam Rods
- ​7/16" ARP 2000 Rod Bolts
-
JE ULTRA Pistons
- Heavy Duty Strutted Forging
- Lateral Gas Ports for better top ring seal
- Ceramic Dome Thermal Barrier Coating JE
- Perfect Skirt Coating
- .230" Wall Tool Steel Wrist Pins
-
JE Pro Steel Piston Rings
- ​Gas Nitrided Steel Top, Napier 2nd, 3 Piece Oil
- Clevite H-Series Main Bearings
- Cleivte H-Series Rod Bearings
This Rotating Assembly is a good option for Forced Induction applications in the 900 - 1500 HP range. The Pistons supplied in this kit come standard with all available upgrades and are capable of handling 35lbs + of boost.
Compression Ratios are configured with a 57cc Chamber, 3.700" x .040" Head Gasket and .005" Piston to Deck clearance.
*Internal Balancing Available
- Rods and Pistons weight matched to +/- 0.1g
- Crankshaft Balanced to +/- 0.2g
We offer in-house balancing for all rotating assemblies and highly suggest having us balance the assembly for you. Normally these assemblies will require a slug of heavy metal installed into each end of the crankshaft due to the bobweight. Most shops will charge $75.00 per slug, installed. If you purchase the assembly and the balancing option at the same time, we waive the heavy metal fee.
Details
- MHS-500017C
- MHS-500017C
- Modular Head Shop
- New
Categories
Shipping Information
- Item Requires Shipping
- 85.0 lbs.
- W24.0000” x H24.0000” x L36.0000”
- Free Shipping!
