MHS Competition Gen 1/2 5.0L Coyote Oil Pump Assembly

Modular Head Shop Competition Oil Pump Assembly for Gen 1/2 Coyotes Engines

• OEM Ford Gen 1/2 5.0L Coyote Mustang GT Oil Pump Housing
• MHS S7 Tool Steel .560" Wide Gerotor Gear Set
  • 100% Machined and Heat Treated in the USA
  • Mid 50's Rockwell Hardness - will handle some pre-filter contamination without galling.
  • Wire EDM Machined for tight tolerances
  • Tested on multiple engines to 9500+ RPM and 2000+ HP.
• 3/32" Viton Flange Seal O-Ring on Pump Backing Plate to Block face

This is the same Oil Pump Assembly that we use in all of our in house 5.0L Coyotes based builds. We have been using the same material and design pump gear sets for over 8 years on both the 4.6L / 5.4L  and 5.0L platforms with excellent results. Recently we have added a Viton O-Ring Flange Seal to the backing plate to help with any oil pressure loss where the oil pump meets the block.
